Proel WD12A Monitor

Proel WD12A Monitor

Click here to see similar items, and to buy from eBay.

Proel WD12A – Active Stage Monitor
Showing signs of wear due to it actually being used for acoustic gigs. Has been recently serviced and has been PAT tested, works as it should without any problems. Good steady wooden cabinet, excellent bass and clear deliverance. I’ve never really had to push the driver too much but it can really punch out some volume if needed. Monitor or front of house setting.
Collection on this item is available as postage is going to be expensive due to weight and size.
Mains included
The WEDGE Series is a complete range of active stage monitors designed to offer not only to professional musicians and rental companies, but also to amateur musicians and nonprofessional users, a highly valuable monitoring solution at a very affordable price. The WEDGE stage monitors provide a perfect sound intelligibility and a high SPL in an extremely light-weight and portable enclosure. The coaxial transducers, designed under PROEL specifications, represent the best choice for stage monitors, not only because they fit into more compact cabinets, but also for the fact that they provide a perfect alignment in the emission of high and low frequencies and a controlled directivity for a perfect listening from any position. The lightweight CLASS D amplifier modules with SMPS, coupled to a sophisticated analog processing, provide an impressive sound pressure level, with an extremely detailed response, particularly in the vocal range, and a remarkable resistance to feedback. Two tailored EQ PRESETS are available for the use of the speaker not only for stage monitoring (MONITOR), but also as a MAIN SOUND SYSTEM (FOH). The low-profile, stylish and unobtrusive cabinet, with recessed handles and scratch-resistant polyurethane painting, fits perfectly on any stage. WD12A, with its high SPL and its fullrange response, is the favorite choice for vocals, guitar, horns and electronic instruments or as a high-power monitor for DJs.1 compression driver with 1.35 VC12 woofer with 2.5 VC700 W total peak power50 W continuous class AB amplifier for the high frequencies300 W continuous class D amplifier for the low frequenciesSwitch Mode Power Supply (SMPS)Dual LIMITER circuit2 optimized EQ PRESETS for MONITOR or FOH (Front-Of-House) useSPL MAX: 124dBFrequency response: 50 Hz – 20 kHzLightweight plywood cabinet with black anti-scratch polyurethane paintReinforced metal grilleRecessed connection panel for added protectionTwo recessed handles for easy transportPole adapterTECHNICAL SPECIFICATIONS
System type2-way coaxial ventedLow Frequency Device12 woofer with 2.5″VCHigh Frequency Device1 compression driver with 1.35″VCAngular Coverage80Frequency Response50 Hz – 20 kHzMax SPL at 1mt (peak)124 dBAmplifier Continuous PowerHF: 50 W CLASS ABLF: 300W CLASS D with SMPSInput Impedance30 kohm balanced / 15 kohm unbalancedInput sensitivity0 dBuControlsLEVEL, PRESET selector (MONITOR, FOH), GND liftConnectorsINPUT: COMBO (XLR-F/JACK) – LINK: XLR-MPower Supply230 VAC or 120 VAC 50/60 HzMaximum Consumption445 WRated Consumption*235 WConstructionPlywood with black anti-scratch polyurethane paintPole adapter1 x sideHandles2 x sidesMonitor Taper36 Weight15 kg (33 lb)Dimensions (W x H x D)510x340x500 mm* Rated consumption is measured with pink noise with a crest factor of 12 dB, this can be considered a standard music program.
